Kyocera TASKalfa 7002i - Page 489

2WA/2NJ/2RK
4-161
7. Remove the screw (a)(M4x8).
Figure 4-239
8. Remove two screws (a)(M4x8) and
then remove the ISU right cover (b).
9. Release six hooks (c) and remove the
right upper cover (d).
Figure 4-240
a
14j0215
a
d
b
c
c
c
d
14j0216
