2WA/2NJ/2RK
6-143
Setting: LCF
1.Select the item to set.
2.Select [Execute].
3.Press the [Start] key. Each operation starts.
* :To stop the operation of the motor, press the [Stop] key.
Execution: Side Deck
1.Select the item to set.
2.Select [Execute].
3.Press the [Start] key. Each operation starts.
4.To stop the motor drive, press the [Stop] key.
Execution: SMT
1.Select the item to set.
2.Select [Execute].
3.Press the [Start] key. Each operation starts.
4.To stop the operation, press the [Stop] key.
Display Contents
Motor Off PF paper feed motor OFF
On PF paper feed motor ON
Clutch C1 Clutch PF paper feed clutch 1: ON
C2 Clutch PF paper feed clutch 2: ON
Feed1 Clutch PF horizontal conveying clutch 1: ON
Feed2 Clutch PF horizontal conveying clutch 2: ON
Execute Starts operation
Display Contents
Motor Off SD paper feed motor OFF
On SD paper feed motor ON
Clutch C1 Clutch SD paper feed clutch: ON
Cassette1 Solenoid SD paper feed solenoid: ON
Execute Starts operation
Display Contents
Motor Off PF paper feed motor OFF
On PF paper feed motor ON
Clutch C1 Clutch PF paper feed clutch: ON
Feed1 Clutch PF conveying clutch : ON
Feed2 Clutch PF conveying clutch : ON
Feed 3 Clutch PF conveying clutch : ON
Separator Solenoid PF paper feed-shift solenoid: ON
Execute Starts operation
