Turn the motor and clutch power on for each feed unit.
Purpose
Execute to check motor and clutch operation of each feed unit.
Execution
1.Press the [Start] key.
2.Select the item to operate.
* :The screen for setting is displayed.
Setting: 2PF
1.Select the item to set.
2.Select [Execute].
3.Press the [Start] key. Each operation starts.
* :To stop the operation of the motor, press the [Stop] key.
U247 Paper feed operation check
(Message: Check Paper Feeder)
Items Contents
2PF Operates 2-tray paper feeder
LCF Operate the high capacity feeder
Side Deck Operate the side feeder
SMT SMT SSW
Side 2PF Side PF Boot
Side LCF Side large capacity feeder
Display Contents
Motor Off PF paper feed motor OFF
On PF paper feed motor ON
Clutch C1 Clutch PF paper feed clutch 1: ON
C2 Clutch PF paper feed clutch 2: ON
Feed1 Clutch PF conveying clutch 1: ON
Feed2 Clutch PF conveying clutch 2: ON
Execute Starts operation
To Next Page
