2WA/2NJ/2RK
6-180
Description
Execute the automatic adjustment of the timing at the print engine
Adjusting the leading edge timing, enter line and margins
Purpose
Used to make respective auto adjustments for the print engine.
* : Execute this mode in a simplified manner when the Chart B(302AC68243) is not available.
Execution
1.Set A3/Ledger paper.
* :Load A4/Letter when the large capacity feeder is used.
2.Press the [Start] key.
3.Select the [Execute].
4.Press the [Start] key.
* :A test pattern is outputted.
5.Set the output Test Pattern 2 as the original.
6.Press the [Start] key.
* :Automatically perform adjustment from the top to bottom cassettes.
7.When normally completed, [OK] is displayed.
* :An error code appears when there is an error.
Error codes list
Completion
Press the [Stop] key.
* :The screen for selecting a maintenance item No. is displayed.
U415 Adjusting the print position automatically
(Message: Print Position Auto Adjust)
Display Contents Display Contents
S001 Black band is not detected (main
scanning direction far end)
C101 Adjustment value error (main
scanning direction magnification)
S002 Black band is not detected (main
scanning direction near end )
C102 Adjustment value error (auxiliary
scanning direction magnification)
S003 Black band is not detected (auxil-
iary scanning direction leading
edge)
C103 Adjustment value error (leading
edge timing)
S004 Black band is not detected (auxil-
iary scanning direction trailing
edge)
C104 Adjustment value error (center
line)
S005 Auxiliary scanning direction skew
error (1.5 mm or more)
C105 Adjustment value error (B margin)
S006 Main scanning direction skew error
(1.5 mm or more)
C106 Adjustment value error (A margin)
S007 Original error (detection of reverse
original paper)
C107 Adjustment value error (C margin)
S008 Original error (page mismatch) C108 Adjustment value error (D margin)
SFFF Other scanner error CFFF Other controller error
To Next Page
