2WA/2NJ/2RK
6-181
Description
Enter the lab values which are shown on the back page of the adjustment original (P/N:
7505000005).
Purpose
Enter data in order to correct for differences in originals during the automatic adjustment
Method
1.Press the [Start] key.
2.Select the item to set.
Method: ChartA
1.Press the [Start] key.
2.Select the item to set.
Setting: White
1.Select the item to set.
2.By using [Left/Right cursor] keys or the numeric keys, enter the values which are shown on the
back page of the adjustment original.
3.Press the [Start] key to set the setting value.
U425 Set Target
(Message: Set Target Adjustment Value)
Items Contents
ChartA Setting the adjustment value of the table scanning
ChartB Sets the adjustment value of the DP scanning
Items Contents
White Setting the white patch for the adjustment original
Black Setting the black patch for the adjustment original
Gray1 Setting the Gray1 patch for the adjustment original
Gray2 Setting the Gray2 patch for the adjustment original
Gray3 Setting the Gray3 patch for the adjustment original
C Setting the cyan patch for the adjustment original
M Setting the magenta patch for the adjustment original
Y Setting the yellow patch for the adjustment original
R Setting the red patch for the adjustment original
G Setting the green patch for the adjustment original
B Setting the blue patch for the adjustment original
Adjust Original Setting the main scanning and sub-scanning directions
Items Contents Setting range Data
variation
Initial
setting
L L parameter setting 0.0 to 100 - 93.6
a A value setting -200 to 200 - 0.9
b B value setting -200 to 200 - -0.4
