2WA/2NJ/2RK
6-215
* :Initial setting: 14400bps
2.Press the [Start] key to set the setting value.
* :[Completed] is displayed.
Setting: TX Echo
Sets the time to send the DCS signal after the DIS signal is received. Execute when an error
occurs with echo at the transmitter side.
1.Select the item to set.
* :Initial setting: 300
2.Press the [Start] key to set the setting value.
* :[Completed] is displayed.
Setting: RX Echo
Sets the time to send the NSF, CSI or DIS signal after the CED signal is received. Execute when
an error occurs with echo at the receiver side.
1.Select the item to set.
* :Initial setting: 75
2.Press the [Start] key to set the setting value.
* :[Completed] is displayed.
Completion
Press the [Stop] key.
* :The screen for selecting a maintenance item No. is displayed.
Items Contents
500 Sends the DCS 500 ms after receiving a DIS.
300 Sends the DCS 300 ms after receiving a DIS.
Items Contents
500 Sends the NSF, CSI or DIS 500ms after receiving the CED.
75 Sends the NSF, CSI or DIS 75ms after receiving the CED.
