Labconco Axiom C1 User Manual

11
Clearance Requirements
A minimum clearance of at least 6 inches (150 mm) is suggested on the top and both
sides of the product for service.
See Appendix B: Dimensions for overall product dimensions.
Electrical Requirements
The product models have the following electrical requirements.
Catalog Number
Typical Operating
Current (Amps)
Electrical Circuit Requirements
1
3044xxx01
4 A
115 V, 60 Hz, 16 A
1 Phase
3044xxx21
4 A
100 V, 50/60 Hz, 16 A
1 Phase
3044xxx-11, 31, 41, 51, 61, 71
2 A
230 V, 50/60 Hz, 8 A
1 Phase
3046xxx01
5 A
115 V, 60 Hz, 16 A
1 Phase
3046xxx21
5 A
100 V, 50/60 Hz, 16 A
1 Phase
3046xxx-11, 31, 41, 51, 61, 71
2.5 A
230 V, 50/60 Hz, 8 A
1 Phase
A dedicated outlet with an appropriate circuit breaker should be located as close as
possible to the product, but no greater than 10 feet (3 m). Consult your local electrical
codes for properly rated circuit breakers. For safe operation the dedicated outlet must
provide a protective earthing ground connection to the product.
On 100V and 115V models, both internal electrical outlets are protected by a ground
fault interrupter circuit (GFIC). Labconco does NOT recommend connecting the
product’s power cord into a GFIC outlet. GFIC outlets can nuisance trip, resulting in
complete removal of power to the product. Such a scenario would result in complete
loss of product and/or personnel protection.
Service Line Requirements
All utility service lines should be ¼ inch O.D., brass, copper, or stainless steel, and
equipped with an easily accessible shut-off valve. The service valves are rated for
operation at 40 PSI (275 kPa). If the service line pressure exceeds this, it must be
equipped with a pressure regulator to reduce the line pressure.
Note: The use of flammable gases or solvents should be avoided in the biosafety
cabinet. Open flame in the cabinet will disrupt the laminar airflow in the cabinet and may
damage the HEPA filters. Flammable gases or solvents may reach explosive
concentrations in the cabinet or ductwork. If you feel that the procedure requires the use
of an open flame or flammable materials, contact your institution’s safety office.
1 Electrical Requirements, ‘V’ = VAC (Voltage with alternating current), ‘A’ = Amperes
