Center Drip Tray Removal
Before beginning, the center work surface must be hinged open or removed, and the
wing work surfaces removed as described previously. Reference Figure 8-3 for parts
identification.
1. If not already on, turn the cabinet blower on.
2. Grasp the knob located in the center of the center drip tray. Pull the knob up to
hinge the center drip tray up about 2 inches (50 mm).
3. Grasp the front or side edges of the Center Drip Tray, and pull forward while
continuing to rotate the front edge up.
If removing the center drip tray from the cabinet, the drip tray must be thoroughly
decontaminated before removing it from the cabinet.
To reinstall the center drip tray, hold the front edge higher than the back edge, and
gently set the back edge on the exhaust duct flange. Slide the center drip tray
backwards while also hinging it down and into its final position. Take care to engage the
two aligment tabs on the front edge of the center drip tray into the cutouts in the front
grille.
Front Grille Removal
Before beginning, the center work surface must be hinged open or removed, the wing
work surfaces removed, and the center drip tray removed as described previously.
Reference Figure 8-3 for parts identification.
1. If not already on, turn the cabinet blower on.
2. Grasp the front grille with two hands, one on the inside edge and one on the
outside edge. Pull the front grille up, while also rotating the top slightly inward.
Note: It may be difficult to raise the front grille at first. If so, move to one end of
the front grille, and follow step #2 while also rotating the grille up on that end.
Once one end has raised slightly, then move back to the middle and continue to
lift it up.
If removing the front grille from the cabinet, the front grille must be thoroughly
decontaminated before removing it from the cabinet.
