7: Using Your Axiom Type C1
This section details the functional features and proper techniques for safely and
efficiently using the Axiom Type C1 biosafety cabinet.
Feature Overview
Figure 7-1 illustrates key features and components of the product.
Inlet Relief Valve
Reset Switch
(optional) UV Lamp
Work Surface Latch
Sash Position Label
Glass Sash
Wing, RH
Main Work Surface
Wing, LH
Vacu-Pass (optional)
Service Fixture (optional)
LCD Display
Keypad
GFIC outlet, RH
Attachment Point
Optional IV Bar
Figure 7-1
