Appendix B: Dimensions
Table B-1 and Figure B-1 indicate the product dimensions. All dimensions shown in
inches (centimeters).
64.2
C
25.0
17.6
25.7
32.7
A
B
E
10.2
Power Cord Inlet
D
O 10.1 ID
Width
A
B
C*
D
E
4'
48.5
(123.2)
54.3
(137.9)
22.5
(57.2)
8.0 (20.3)
17.1
(43.4)
10.0 (25.4)
6'
72.5
(184.2)
78.3
(198.9)
22.5
(57.2)
8.0 (20.3)
28.2
(71.5)
10.0 (25.4)
*Bag In Bag Out Exhaust Filter Models C = 13.6 (34.5)
Table B-1
Figure B-1
