Labconco Purifier Logic+ 30132 User Manual

Product Service 1-800-522-7658
119
4. To reinstall the diffuser, ensure that the two holes on the back edge of the
diffuser align with the diffuser support pins on the rear wall of the work area, as
shown in Figure 6-35.
Figure 6-35
Diffuser pins engaging the holes in the
rear of the diffuser.
