Labconco Purifier Logic+ 30132 User Manual

Product Service 1-800-522-7658
97
Section 6
Logic+ Service Operations
This section will review the tools needed, and common service operations for the
Logic+.
Recommended Tools for Service
The tools needed for most common service operations are:
 Logic+ Certifier Kit, Labconco Part # 3858403
 #2 Phillips Screwdriver or long bit for cordless drill
 ½-inch Socket with extension and ratchet
 ½-inch nut driver
 7/16-inch socket or nut driver
 5/16-inch socket or nut driver
Optional tools that may be needed include:
 Cordless screwdriver/drill
 Cordless ratchet
 3/8-inch nut driver or socket and ratchet
 Pliers
 10-24 Tap
 5/16 x 18 Tap
Note: If you use a cordless drill with an adjustable torque setting, set the
torque as low as possible to properly drive the screw or bolt.
External Dress Components
Front Dress Panel Removal and Installation
Figure 6-1
1. Locate and remove the two Phillips screws that secure
the front panel as shown in Figure 6-1. They are
located on the bottom corners of the front dress panel
2. Swing the bottom of the dress panel out to clear the
fluorescent light and then lift the front dress panel
straight up and away from the cabinet.
