Product Service 1-800-522-7658
87
Table 5-5
Inflow Test Specifications – 8 inch Sash Opening
Width (feet)
3
4
5
6
Nominal Average Inflow
(FPM)
105+/-5
105+/-5
105+/-5
105+/-5
Sash Open Area (Sq. Ft)
2.03
2.69
3.36
4.03
Nominal Avg. Exhaust Vol.
(CFM)
213
283
353
423
Avg. Exhaust Vol. Range
(CFM)
203-223
269-296
336-370
403-443
Inflow Test Specifications – 9 inch Sash Opening
Width (feet)
3
4
5
6
Nominal Average Inflow
(FPM)
105+/-5
105+/-5
105+/-5
105+/-5
Sash Open Area (Sq. Ft)
2.28
3.03
3.78
4.53
Nominal Avg. Exhaust Vol.
(CFM)
240
318
397
476
Avg. Exhaust Vol. Range
(CFM)
228-251
303-333
378-416
453-498
Inflow Test Specifications – 10 inch Sash Opening
Width (feet)
3
4
5
6
Nominal Average Inflow
(FPM)
105+/-5
105+/-5
105+/-5
105+/-5
Sash Open Area (Sq. Ft)
2.53
3.37
4.2
5.03
Nominal Avg. Exhaust Vol.
(CFM)
266
354
441
529
Avg. Exhaust Vol. Range
(CFM)
253-278
337-371
420-462
503-553
Inflow Test Specifications – 12 inch Sash Opening
Width (feet)
3
4
5
6
Nominal Average Inflow
(FPM)
85+/-5
85+/-5
85+/-5
85+/-5
Sash Open Area (Sq. Ft)
3.04
4.04
5.04
6.04
Nominal Avg. Exhaust Vol.
(CFM)
259
344
428
514
Avg. Exhaust Vol. Range
(CFM)
243-274
323-364
403-454
483-544
Acceptance
Average inflow shall be meet the specified value.
