34 Safety
Figure 2-15
Suction line shut-off valve
NOTE: The hydraulic tank model may vary according to the options installed on the vehicle.
3. Start the truck.
Once the engine is started, wait for the air pressure to build up to at least 70 PSI.
Figure 2-16
Air pressure indicator
IMPORTANT: Do not operate or move the vehicle until the air pressure has reached 70 PSI.
4. Engage the hydraulic system by switching ON the Pump ON/OFF switch on the in-cab control
panel (see Figure 2-17).
The switch will turn from blue to green.
Warning!
Failure to fully open the shut-off valve before starting the truck will cause immediate
damage to the pump, even if the pump is not activated.
To Next Page
