Controls and Indicators 43
ESTOP:Left Panic Bar Release Left Panic Bar
ESTOP:Right Panic Bar Release Right Panic Bar
FullEject:Cab EStop Pull Out Cab EStop Button
FullEject:Ext. Control Selected Deactivate Ext. Control
FullEject:Packer Not Retracted Retract Packer
FullEject:Pump Not Started Engage Pump
Gripper Open:Arm Too High Lower Arm
High Hydraulic Oil Temp. Turn Off Engine and Refer to your
Maintenance Personnel
Low Hydraulic Oil Add Hydraulic Oil
Packer Extend:Air Weigh Signal Unload Body
Packer:Already Extended Refer to Maintenance Personnel or
LabriePlus
Packer:Already Retracted Refer to Maintenance Personnel or
LabriePlus
Packer:External Control Deactivate External Control
Packer:Pump Not Started Engage Pump
Packer:Tailgate Not Fully Open Open Tailgate Completely
Pump Not Started: Aux Cab EStop Pull Out Aux Cab EStop Button
Pump Not Started:Cab EStop Pull Out Cab EStop Button
Pump Not Started:Left Estop Pull Out Left EStop Button
Pump Not Started:Left Panic Bar Release Left Panic Bar
Pump Not Started:Right Estop Pull Out Right EStop Button
Pump Not Started:Right Panic Bar Release Right Panic Bar
Pump Not Started:RPM Too High Lower Engine Speed Below
900 RPM
Pump:Aux. AutoDump Switch ON Release Aux. AutoDump Switch
prior to Engaging Pump
Pump:Aux. CloseGripper Switch ON Release Aux. CloseGripper Switch
prior to Engaging Pump
Table 1 Warning messages (cont’d)
Warning and Caution Messages Solution
