Labrie MINIMAX - Rubber pads; Gripper limit switch

90 Operating the MINIMAX
TM
8. Check for missing rubber pads on gripper.
Figure 4-3 Rubber pads
9. Check the limit switches. Refer to the Maintenance Manual for more details.
Figure 4-4 Gripper limit switch
Figure 4-5 Mid-height limit switch (left), parked limit switch (right)
