1. 2 Se ns o r Se l e ct i o n 5
| www.lakeshore.com
Model Useful Range Magnetic Field Use
Diodes
(3062)
Silicon Diode DT-670-SD 1.4 K to 500 K T # 60 K & B " 3 T
Silicon Diode DT-670E-BR 30 K to 500 K T# 60 K & B " 3 T
Silicon Diode DT-414 1.4 K to 375 K T # 60 K & B " 3 T
Silicon Diode DT-421 1.4 K to 325 K T # 60 K & B " 3 T
Silicon Diode DT-470-SD 1.4 K to 500 K T # 60 K & B " 3 T
Silicon Diode DT-471-SD 10 K to 500 K T # 60 K & B " 3 T
GaAlAs Diode TG-120-P 1.4 K to 325 K T > 4.2 K & B " 5 T
GaAlAs Diode TG-120-PL 1.4 K to 325 K T > 4.2 K & B " 5 T
GaAlAs Diode TG-120-SD 1.4 K to 500 K T > 4.2 K & B " 5 T
Positive Temperature
Coefficient RTDs
100 ) Platinum PT-102/3 14 K to 873 K T > 40 K & B " 2.5 T
100 ) Platinum PT-111 14 K to 673 K T > 40 K & B " 2.5 T
Rhodium-Iron RF-800-4 1.4 K to 500 K T > 77 K & B " 8 T
Rhodium-Iron RF-100T/U 1.4 K to 325 K T > 77 K & B " 8 T
Negative
Temperature
Coefficient RTDs
Cernox™ CX-1010 0.3 K to 325 K
1
T > 2 K & B " 19 T
Cernox™ CX-1030-HT 0.3 K to 420 K
1, 3
T > 2 K & B " 19 T
Cernox™ CX-1050-HT 1.4 K to 420 K
1
T > 2 K & B " 19 T
Cernox™ CX-1070-HT 4 K to 420 K
1
T > 2 K & B " 19 T
Cernox™ CX-1080-HT 20 K to 420 K
1
T > 2 K & B " 19 T
Germanium GR-200A-100 0.3 K to 100 K Not recommended
Germanium GR-200A-250 0.5 K to 100 K Not recommended
Germanium GR-200A/B-500 1.4 K to 100 K Not recommended
Germanium GR-200A/B-1000 1.4 K to 100 K Not recommended
Germanium GR-200A/B-1500 1.4 K to 100 K Not recommended
Germanium GR-200A/B-2500 1.4 K to 100 K Not recommended
Carbon-Glass CGR-1-500 1.4 K to 325 K T > 2 K & B " 19 T
Carbon-Glass CGR-1-1000 1.7 K to 325 K
2
T > 2 K & B " 19 T
Carbon-Glass CGR-1-2000 2 K to 325 K
2
T > 2 K & B " 19 T
Rox™ RX-102 0.3 K to 40 K
3
T > 2 K & B " 10 T
Rox™ RX-103 1.4 K to 40 K T > 2 K & B " 10 T
Rox™ RX-202 0.3 K to 40 K
3
T > 2 K & B " 10 T
Capacitance
3061
CS-501 1.4 K to 290 K T>4.2 K & B " 18.7 T
Thermocouples
3060
Type K 9006-006 3.2 K to 1505 K Not recommended
Type E 9006-004 3.2 K to 934 K Not recommended
Chromel-AuFe 0.07% 9006-002 1.2 K to 610 K Not recommended
1
Non-HT version maximum temperature: 325 K
2
Low temperature limited by input resistance range
3
Low temperature specified with self-heating error: " 5 mK
TABLE 1-1 Sensor temperature range
