1.3.6 Interface
1.3.7 General
IEEE-488.2
Capabilities SH1, AH1, T5, L4, SR1, RL1, PP0, DC1, DT0, C0, E1
Reading rate To 10 rdg/s on each input
Software support LabVIEW™ driver (contact Lake Shore for availability)
USB
Function Emulates a standard RS-232 serial port
Baud Rate 57,600
Connector B-type USB connector
Reading rate To 10 rdg/s on each input
Software support LabVIEW™ driver (contact Lake Shore for availability)
Ethernet
Function TCP/IP web interface, curve handler, configuration backup,
chart recorder
Connector RJ-45
Reading rate To 10 rdg/s on each input
Software support LabVIEW™ driver (contact Lake Shore for availability)
Alarms
Number 4, high and low for each input
Data source Temperature or sensor units
Settings Source, high setpoint, low setpoint, deadband, latching or
non-latching, audible on/off, and visible on/off
Actuators Display annunciator, beeper, and relays
Relays
Number 2
Contacts Normally open (NO), normally closed (NC), and common (C)
Contact rating 30 VDC at 3 A
Operation Activate relays on high, low, or both alarms for any input, or
manual mode
Connector Detachable terminal block
Ambient temperature 15 °C to 35 °C at rated accuracy;
5 °C to 40 °C at reduced accuracy
Power requirement 100, 120, 220, 240, VAC, ±10%, 50 or 60 Hz, 250 VA
Size 435 mm W × 89 mm H × 368 mm D
(17 in × 3.5 in × 14.5 in), full rack
Weight 7.6 kg (16.8 lb)
Approval CE mark
