lancer TP30 - Unit Wiring Diagram; DIP Switch Legend

46
Unit Wiring Diagram - 115 Volt
115VAC
OUT
115VAC
IN
7A Brea ker
3
IBD PCB
J7 J5
J11
27DC
24DC
3.5A Breaker
3.5A Breaker
J6
UDC2 TOP
UDC2 BOTTOM
F AN
Valves Left Side
Valves Right Side
Left
Nozzle
Cup
Lights
Right
Nozzle
Cup
Lights
AU GER
MOTOR
AGITATION
MOTOR
ICE DOOR
SOL ENOID
microbus
16POS
HDMI USB A
POWER
JA CK
SD
HDMI
USB B
POWER
INPUT
OUTP UT
KEYSWIT CH
LCD DISPLAY
USB
ADA
ETHERNET
ETHERNET
COUPLER
USB
DC BL O C K
OK
^
^
^
^
POWER CORD
CONDENSATION
FAN
P RI MAR Y PC B
SECONDARY PCB
POUR
BUTTON
POUR
BUTTON
GPI O
ICE DOOR
TRIGGER
VALVE HARN RIGHT
VALVE HARN LEFT
SBC
DIO PC B
POWER SUPPLY
USB A
MALE TO
USB A
FE MALE
DC1
DC2
USB A
TO
USB B
*= DENOTES DEFAULT
32
SW2 SWITCH 2: POSITION DOES NOT
MATTER
4
ON
LANCER PN: 06-3289/01
SW1
5258
ON
1
ON
SW1
8
SW1 SWITCH 2: NOT USED FOR
THIS DISPENSER
1
6
873
6
SW2 SWITCH 1: MUST BE ON FOR
THIS DISPENSER
SW2
7
6
7
6
2
2
3 83
4
7
4
5
SW1 SWITCH 1: NOT USED FOR
THIS DISPENSER
ON
5
4
SWITCH #
AGITATOR ON
TIME
56
OFF OFF 11 SECONDS
OFF ON 9 SECONDS
*ON OFF 7 SECONDS
ON ON 5 SECONDS
SWITCH #
AUGER RUN TIME
78
OFF OFF
6 SEC DISPENSED
OFF ON
9 SEC DISPENSED
*ON OFF
12 SEC DISPENSED
ON ON
15 SEC DISPENSED
SWITCH #
AUTO AGITATE
OFF TIME
34
*OFF OFF
NO AUTO AGITATION
OFF ON 20 MINUTES
ON OFF 40 MINUTES
ON ON 60 MINUTES
DIP Switch Legend
