SPECIFICATIONS AND FEATURES
IBD BOLD 30i
DIMENSIONS
Width: 30.00 inches (762 mm)
Depth: 34.00 inches (863.6 mm)
Height: 40.60 inches (1031.24 mm)
WEIGHT
Shipping: 290 lbs (132 kg)
Operating (w/ Ice): 570 lbs (259 kg)
Ice Capacity: 280 lbs (127 kg)
CARBON DIOXIDE (CO
2
) SUPPLY
Min Pressure: 70 psi (0.483 MPa)
Max Pressure: 80 psi (0.552 MPa)
FITTINGS
Carbonator Inlet: 3/8 inch barb
Plain Water Inlet: 3/8 inch barb
Brand Syrup Inlets: 3/8 inch barb
Ambient Flavor Inlets: 3/8 inch barb
CO
2
Inlet: 3/8 inch barb
ELECTRICAL
120 VAC / 60 Hz / 5.0 Amps
220/240 VAC / 50/60 Hz / 2.5 Amps
CARBONATED WATER SUPPLY
Min Flowing Pressure: 25 psi (0.172 MPa)
Max Static Pressure: 50 psi (0.345 MPa)
PLAIN WATER SUPPLY
Min Flowing Pressure: 75 psi (0.517 MPa)
This unit emits a sound pressure level below 70 dB
Max Altitude: 16,400 ft (5,000 m)
30.00 in
34.00 in
40.60 in
A
B
C
D
A. Top Cover
B. Touchscreen Display
C. Splash Plate
D. Cup Rest/Drip Tray
