PLMNL0243 REV. A, Effective Date: 03/24/16 62 FiberMINI ™ 2.0 Operation Manual
 Welding End Effector: See Figure 86.
Figure 86
Focal
Length
(mm)
A
(mm)
ALH
Spacer
LMB
Spacer
100
96.5
None
PLSBA0268
125
121.5
PLSBA0261
PLSBA0268
150
146.5
PLSBA0262
PLSBA0269
200
196.5
PLSBA0262
PLSBA0270
 Air Knife End Effector: See Figure 87.
Figure 87
Focal
Length
(mm)
A
(mm)
B
(mm)
ALH
Spacer
LMB
Spacer
100
NA
NA
NA
NA
125
NA
NA
NA
NA
150
145.5
166.0
± 6.5
PLSBA0262
PLSBA0268
200
145.5
216.0
± 6.5
PLSBA0262
PLSBA0268
The spacer block is threaded. It is mounted between
the lens manifold block and the air knife.
