Laser Technology IMPULSE LR User Manual

T
AKING A
H
EIGHT
M
EASUREMENT
Page 28 Electronic Copy of LTI’s Impulse User’s Manual 8
th
Edition © October 1998
Button/Action Result (example)
Press Fire to
turn on the
instrument
RIGHT HD
_ _ _ _ _ _
F
Press Back to
reach the Height
indicator
RIGHT HT
Press Fire to
advance into
the height
subprocedure
RIGHT
_ _ _ _ _ _
F
HT HD
Button/Action Result (example)
Sight the target
through the
scope
Press Fire to
take the
horizontal
distance
measurement
RIGHT
F
HT
INC
DNLD
HD
Aim to the base
of the object
(even if you
can’t sight it),
and press Fire
to take the base
inclination
reading
RIGHT
D
HT
DNLD
INC
