Laser Technology IMPULSE LR User Manual

T
HE
E
DIT
M
ODE
Page 49 Electronic Copy of LTI’s Impulse User’s Manual 8
th
Edition © October 1998
The Impulse has an editor which can be used to
manually enter numeric values for the range offset,
gate distances, the set point of difference distance
measurements, and in the Impulse 200, the height
pivot offset and tilt calibration offset.
The range offset, height pivot offset, and tilt
calibration offset are always input manually, and
entering these submenus automatically invokes the
editor.
When it is more desirable to manually input gate
distances and the set point of difference distance
measurements rather than shooting them in with
the laser, an optional editor is available by pressing
Fire2 when a distance measurement is requested
by the Impulse.
Once in the editor, follow this method:
• The left-most digit will be flashing. Press
Forward2 or Back2 to toggle the first digit
between zero (which represents a positive
value) and the minus sign (-). Negative values
are not allowed for a height pivot offset.
• Fire2 advances the edit to the next digit to the
right. Use Forward2 and Back2 to increment or
decrement the value of the digit. Repeat this
step as necessary to advance through each
digit in the entire distance value and edit each
digit individually.
The distance value can be cleared to zero at any
time by long-pressing the Back key. Once altered
or cleared, the original distance value can be
restored by pressing either Forward or Back.
