7 Specifications
CUTTING HEAD
Power Rating .............................................................................................................................. up to 4 kW
Focusing Lens (Effective Focal Length) ................................................. 75mm, 104mm, 130 mm, 150 mm
Focusing Lens (Diameter) ................................................................................................................. 28 mm
Clear Aperture ................................................................................................................................... 25 mm
Nozzle Tip .......................................................................................................................... Various Shapes
Assist Gas Pressure ............................................................................................................... up to 20 BAR
Gas .................................................................................................................................... Female 1/8 NPT
Water Ports ........................................................................................................... 6 mm tube to M5 fittings
Weight ................................................................................................................................................ 3.5 kg
Height (Center Of Travel) ................................................................................................................ 182 mm
Slide Travel .................................................................................................................................. ±12.5 mm
Max. Travel Speed .................................................................................................................. 175 mm/sec.
Standoff Distance Range (1 mm Recommended) .......................................................... 0.5 mm to 2.0 mm
COLLIMATOR
Effective Focal Length (Doublet, Fused Silica) ......................................................................... 78, 102 mm
Recollimating Lens (Diameter) .......................................................................................................... 28 mm
Clear Aperture ................................................................................................................................... 25 mm
Fiber Socket (Others Available On Request) .................................... QBH, HCL-8, LLK-B, QD, LCA, PIPA
CONTROL BOX
Sealed Enclosure ............................................................................... 380 mm L x 300 mm W x 160 mm H
Single Interconnect Cable ................................................................................................... up to 15 m long
Number of Standoff Settings ...................................................................................................................... 7
Electrical Supply ....................................................................................... 85-264 VAC, 1-Phase, 47-63 Hz
Interface Inputs ................................................................ 5-24 VDC, 2.2 kΩ impedance, optically isolated
Interface Outputs ................................................ 12-24 VDC, 150 mA max., sink/source, optically isolated
Specifications are subject to change without notice.
