13 Appendix E – Recommended User-Serviceable Parts List
For recommended user-serviceable spare parts, please call Laser Mechanisms at (248) 474-9480. If your
head requires service beyond the instructions outlined in this manual, please contact Laser Mechanisms for
further assistance.
ITEM
PART #
DESCRIPTION
FIBER INTERFACE ASSEMBLY
1
Fiber Interface Assembly (Contact Laser Mechanisms)
2
PLFTG0081
Tube Fitting
3
PLAJS0001
Adjuster Screw
COLLIMATOR FIXED LENS HOLDERS
4
PLFLH0270
Collimator Fixed Lens Holder 75mm BFL (Complete Assembly)
5
PLFLH0264
Collimator Fixed Lens Holder 100mm BFL (Complete Assembly)
CABLES
6
PLCAB0489
Controller Interface Cable
7
PLCAB0487
Collision Sensor Cable (Not Shown)
ADJUSTABLE LENS HOLDERS
8
PLALH0171
Adjustable Lens Holder 75mm FL (Complete Assembly)
 For use with Tip Retainer Assembly PLTRA0360
9
PLALH0137
Adjustable Lens Holder 100mm FL (Complete Assembly)
 For use with Tip Retainer Assembly PLTRA0360
10
PLALH0138
Adjustable Lens Holder 125mm FL (Complete Assembly)
 For use with Tip Retainer Assemblies PLTRA0360, PLTRA0369, or
PLTRA0417
11
PLALH0143
Adjustable Lens Holder 150mm FL (Complete Assembly)
 For use with Tip Retainer Assemblies PLTRA0369 or PLTRA0417
12
PLSBA0226
Spacer Block 150mm BFL
 For use with Adjustable Lens Holder PLALH0143
COVER GLASS HOLDER
13
PLFLH0123
Fixed Lens Holder
14
PLLCG0034
Lens Cover Glass
15
PLMSR0017
Manifold Seal Ring
TIP RETAINER ASSEMBLIES
16
PLTRA0360
Tip Retainer Assembly 75, 100, or 125mm FL
17
PLTRA0369
Tip Retainer Assembly 125 or 150mm FL
18
PLTRA0417
Tip Retainer Assembly 125 or 150mm FL – Narrow Profile
SCREWS
19
PLSCR0034
Custom Socket Head Cap Screw
O-RINGS
20
PLORG0017
O-ring
ISOLATORS
21
PLISR0033
Tip Isolator
