6.16.6 Displaying serial numbers
Personnel:
n
Operating personnel
1. Select the Serial numbers menu item in the Device status menu.
The serial number of the device is displayed. The serial numbers of
connected modules are also displayed if they are available.
6.17 Programmer
6.17.1 Program example
The programmer function allows storage of temperature/time programs. The
program consists of several temperature/time segments and details about
their repetition. Ramps, temperature jumps (time is zero) or temperature-
holding phases with identical start and end temperature in the segment are
possible. During the start, the current setpoint is stored as the starting value
of the first segment.
The total number of freely programmable segments per program
is 150.
Up to 5 temperature/time programs can be stored.
Setting Description
No. Segment number of the program
Tend End temperature that should be reached
hh Time in hours (hh) by which the specified tem-
perature should be reached.
mm Time in minutes (mm) by which the specified tem-
perature should be reached.
Tolerance The tolerance defines the level of accuracy with
which the end temperature should be reached
before the next segment will be processed.
S1, S2, S3 The switching state of a contact module (if avail-
able) can be programmed here. Contact modules
are available as accessory.
The graphic shows an example of reprogramming a setpoint temperature
profile.
Available settings
V08 Variocool 61 / 97
