Code English output Description
118 SW Valve 1 old Software version of solenoid valve 1 too old
119 SW Valve 2 old Software version of solenoid valve 2 too old
120 SW Valve 3 old Software version of solenoid valve 3 too old
121 SW Valve 4 old Software version of solenoid valve 4 too old
122 SW Pump 0 old Software version of pump 0 too old
123 SW Pump 1 old Software version of pump 1 too old
124 SW Pump 2 old Software version of pump 2 too old
125 SW Pump 3 old Software version of pump 3 too old
126 SW HTC old Software version of high temperature cooler too old
127 SW Ext. Pt100 old Software version of external Pt100 too old
128 SW Ethernet old Software version of Ethernet too old
129 SW EtherCAT old Software version of EtherCAT too old
155 CAN bu. overflow Buer overflow for CAN reception
8.7 Warnings - SmartCool
All warnings of the SmartCool system start with the prefix 3. The
prefix is followed by two additional numbers. These numbers are
listed in the following table.
Code English output Description
301 CAN receive overflow Overflow during CAN reception
302 Watchdog reset Watchdog reset
303 Missing SM adaptation Adaptation run not performed
304 Pressure switch activated Pressure switch in schema cooling circuit was triggered
305 Clean condenser Clean the condenser
306 TO1 out of range (Klixon) Injection temperature outside value range
307 Invalid parameter Inadmissible parameter in memory
308 CAN system Problem during internal data exchange
309 Unknown module Unknown module connected
310 SW Control too old Software version of control system too old
311 SW Safety too old Software version of safety system too old
312 SW Command too old Software version of command remote control unit too old
313 SW Cool too old Software version of cooling module too old
314 SW Analogue too old Software version of analogue module too old
V08 Variocool 77 / 97
