LAUNCH X-431 Module S2 User Manual
37
4.2.8 Electronic throttle valve assembly, air conditioning fan
Wiring mode:
Electronic throttle assembly:
Line 1: SV1\2 +
Line 2: SV1\2 -
*Remarks: This is a coil actuator.
A/C fan:
Line 1: SV1\2 +
Line 2: SV1\2 -
*Remarks: This is a coil actuator.
Operation method:
