3.5.5 Launch Remote Diagnosis (Device-To-PC)
Except that the remote diagnosis can be done between different Launch’s diagnostic tools that come loaded
with the module, user also can ask for remote control from PC client technician.
Slide the switch to ON
Notify the partner of the remote diagnostic web link
Input the partner’s official account and passw ord
Input the Serial Number of your handset
Start Diagnosis
Generate diagnostic report
Fig. R-8
Tap or click the “Web Remote” tab, the screen displays as follows:
Fig. R-8
1. Slide the switch “Allow device to be connected to the WEB client remote diagnostic device” to ON so that
the partner can nd and connect to this device while using the PC.
2. Notify the partner of the PC client website http://remote.x431.com. When the partner accesses the link,
the PC displays as below:
To Next Page
