LeCroy provides you with a recovery application and a backup image in
an extra partition on the instrument’s hard drive. The recovery process is
easy to perform, using the Recovery Wizard. After the recovery
procedure is done, you must activate Windows, either by Internet
connection to Microsoft’s Web site or by telephone. Have your Windows
Product Key number (located on the rear of the oscilloscope) handy
during Widows reactivation.
Running the Acronis True Image Echo Workstation
Recovery Application
1. Connect a network cable to the LAN port on the rear of the
oscilloscope if you intend to activate windows through the
Internet.
2. Connect a keyboard and a mouse to the oscilloscope.
3. Apply power to the oscilloscope.
4. As soon as the Starting Acronis Loader... Press F11 for Acronis
Startup Recovery Manager message appears on the screen, press
the F11 key until the recovery software logo appears momentarily.
The Acronis True Image Echo Workstation main window is
displayed.
Note: Do not press F11 before you see the Starting Acronis
Loader message or you will enter the MB boot sequence
selection.
5. Select Recovery from the Main Menu. The Restore Data Wizard
opens.
6. Click Next on the Welcome page.
7. On the Backup Archive Selection page, you choose the zone
where the recovery partition is located. Choose Acronis Secure
Zone (this is where the recovery data is located on your
oscilloscope) and click Next.
8. On the Backup Date Selection page, choose the date when the
backup was created and to which state you want to revert your
system and click Next.
9. On the Restoration Type Selection page, select Restore disks or
partitions and click Next.
