LeeBoy 7000 - TRUCK HITCH ATTACHMENT (OPTIONAL)

1. After the paver has been started and the motor is
warmedup, paver movements maybe made.
5. When making forward/rearward or turns, always
makethese moves
sloWly. Movethe steering levers
slowly andsmoothlyinthedirectionofintended travel.
FIGURE4
FIGURES
6. When stopping, move both steering levers to the
neutralposition. Seefigure
5.
7. Whenpaving, a constant speedis necessary to lay
an even asphalt mat. Usethe speed lock control to
holdand retain steering leversin a fixed position.
See figure
5.
8. To make a counterrotation movement, the steering
leversaremovedinopposite directions.
1. Toconnecttruckhitchtorearofasphalttruck,extend
the arm extensionsof the truck hitchby pulling on
arm
extensoruever. Seefigure 6.
2. Drivepaver slowlytowardrearof truck
until. roll on
hitch makescontactwith reartiresof truck.
TRUCK HITCH ATTACHMENT
(OPTIONAL)
GENERAL
The truck hitch is an optional attachment to several
"Lee-Boy" pavers. It was designed to improve the
asphaltlayingprocess. Thisis mainlyaccomplished by
keepingthetruckdriveroffhisbrakes,preventing exces-
sive and uneven braking. See operating instruction
below.
ct-.
REVERSE
FIGURE3
FORWARD~
3. Depending on the direction of travel, turning the
pavercanbeaccomplished bypushingor pullingthe
steeringleveron the inside of the turn toward the
neutral position. Refer to figure
4.
4. The traveling speed of the paver can vary greatly,
bypushingorpullingtheforward/reverse leversfrom
neutraltothefullforwardor reverseposition.
2. Todrivethe paverforward,pushthe steering levers
togetherfromtheneutralpositionforward,likewiseto
driveto the rear,pull the steeringleverstowardthe
rearfrom the neutralposition.Referto figure
3.
9
