Design
10 M320 Ref. 10734261 / Version 03 M320 Ref. 10734261 / Version 03 11
5 Design
5.1 Stands
To assemble the stand, note the installation instructions
provided.
1
Rolling floor stand (F12),
long swing arm
Reference model in current user
manual
2
Rolling floor stand, short swing
arm
3
Wall stand (W12)
4
Ceiling mount (C12)
5
Floor stand/baseplate (FP12)
6
Table stand with terminal
(TC12)
7
Wall stand (LW12)
8
Table stand with plate (TP12)
9
Unit Mount*
* Japan Only
(UN12-D 4K)
