Functions
14 M320 Ref. 10734261 / Version 03 M320 Ref. 10734261 / Version 03 15
6 Functions
6.1 Illumination
The illumination of the surgical microscope M320 consists of 2 LEDs.
It is located in the optics carrier.
1
Switch on the main switch.
2
White LED illumination on the
optics carrier lights up.
3
Illumination control for
illumination intensity.
4
Filter and diaphragm controls
for white light, orange filter
and spot illumination.
6.2 Balancing system
With a balanced surgical microscope Leica M320 F12 you can move
the optics in any position without it tilting or falling.
1
Remove the screw.
2
Remove the side cover.
3
Remove the screws.
4
Set the desired position.
Four different positions can be
set.
5
Fasten the screws.
6
Refit the side cover.
