Leica Microsystems M320 - Microscope Carrier; Brake Knobs;Articulation Brakes

Design
12 M320 Ref. 10734261 / Version 03 M320 Ref. 10734261 / Version 03 13
5.4 Microscope carrier
Two different versions are available.
1
Inclined
2
Upright
Upright installation is not possible for models TC12, TP12
and LW12
5.5 Brake knobs/articulation brakes
1
Articulation brake
2
Lever for locking the vertical
position.
3
Joint for balancing
4
Articulation brake
5
Articulation brake
6
Tilt brake
