13 Specifications
13.1 Electrical data
Power socket
Stand F12, W12, C12, FP12, TC12, TP12,
LW12
Centrally located on the control unit
100-240 V AC, 50/60 Hz
Fuse 2 × T 6.3 AH/250 V
Power consumption Leica M320 F12/C12/W12/FP12/TC12/TP12/LW12: 100 VA
Safety class Class I
Control unit Connection sockets for
- Power cable
- HDMI
- USB
13.2 Surgical microscope
Magnification Manual apochromatic 5-step magnification changer 6.4/10/16/25/40×
Stereo base 24 mm
Fix Objective (standard)
Fix Objective (optional)
f=250 mm
f=200, 225, 250, 300, 350, 400 mm
Manual fine focus Objective (optional) f=200, 250, 300 mm
Eyepiece (standard)
Eyepiece (optional)
10 × 21B
12.5 × 17B, 8.33 × 22B, eyepiece 10 × 21B with centered
crosshair graticule
Tilt –30°/+100°
Reset functions Limit switch for light on/off
13.3 Lamps
Light source Direct and long-lasting 2-LED illumination
Average service life of 60,000 h for an end-of-life criterion of 70 % of the initial brightness;
UV filter UV and IR-free LED illumination
Orange filter OG530
Light intensity adjustment Using a drive knob on the optics carrier
