34
7. Start-up
7. Start-up
Note:
Unless otherwise specified, the Leica DM3000
microscope is subject to the same operating in-
structions as the Leica DM2000 microscope.
7.1 Switching on the Microscope
•Switch on the microscope with the on/off
switch (32.1, 33.5).
Caution!
After turning on the gas discharge lamp, the
burner must be immediately adjusted. There-
fore, do not turn on the power supply unit
yet. First, work in transmitted light in order to
familiarize yourself with the microscope’s
controls.
7.2 Köhler Illumination
The condenser is also pre-adjusted in the fac-
tory.
However, in some cases it may be necessary to
re-adjust the condenser. Therefore, check the
condenser centering.
The following procedure is provided for trans-
mitted light-bright field illumination.
• If present: click the condenser disk* into the
BF position.
• If present: pull the light ring slide* out of the
condenser.
Fig. 32 Leica DM2000
1 On/Off switch
2 Focus wheel
3 Stage positioning
21 3
