F1 Set Job:
Only one traverse per job is allowed. If an adjusted or finished
traverse is already part of the selected job, then select another
job. Refer to "6 Apps - Getting Started".
•
F2 Set Tolerances:
Use Tolerances: Yes to activate the use of tolerances.
Enter limits for horizontal direction (the difference between
measured and calculated azimuth to the closing point), distance
(the distance between known and measured closing point), and
for differences in Easting, Northing and Height. If the adjustment
results, or the deviation for a check point, exceed these limits a
warning message appears.
Press Cont to save the limits and return to the Pre-settings
screen.
4.
Select F4 Start to begin the app.
It is not recommended to start a traverse if the memory is almost full. Doing
so, may mean the traverse measurements and results cannot be saved.
Accordingly, a message is displayed if less than 10% of the memory is free.
Description of fields
Field
Option Description
Traverse ID Editable field Name of the new traverse.
Desc. Editable field Description, if desired.
Operator Editable field Name of the user who will be using the new
traverse, if desired.
Method B'F'F"B" All points are measured in face I, then all
points are measured in face II in reverse
sequential order.
B'B"F"F' The backsight point is measured in face I
immediately followed by face II. Other points
are measured in alternating face order.
B'F' All points are measured in face I only.
No. of Sets Selectable list Number of sets. Limited to 10.
Use Face-
Tol.
Selectable list Important when measuring with face I and II.
This checks if both measurements are within
a defined limit. If the limit is exceeded, a
warning message is displayed.
Face-Tol. Editable field The limit that will be used for checking the
face tolerance.
Next step
Press Cont to confirm the traverse configuration and proceed to the Enter
Station Data screen.
☞
Traverse
configuration
136 Apps
