Leisure Unity 2020 - Filling the Fresh Water Tank

WATER AND PLUMBING SYSTEM UNITY MOTORHOME
110
DISCONNECTING THE CITY WATER SUPPLY
1. Turn off the city water supply.
2. Relieve the water pressure in the line by opening a
faucet in the motorhome.
3.
Disconnect the hose from the city water connection
1
.
4.
Replace the protective plug over the city water
connection
1
.
4
1
2
3
FILLING THE FRESH WATER TANK
CITY WATER
1.
Connect the water hose to the city water connection
.
1
2. Turn the water fill selector valve
2
to water tank
fill .
3
3. Turn on the city water supply.
4. Depress and hold the fresh water tank level switch
5
to show the percent-full level on the LED display
6
. Once the fresh water level reads full on the LED
display, turn off the city water supply.
6
10
5
7
5. Turn the water selector valve
2
to the city water
position
4
.
6. Turn on the water pump switch
7
.
7. Slowly open the cold water tap until the water runs
smoothly. Repeat with the hot water taps.
 ᘐ NOTICE
Always turn off the water pump switch
7
if
leaving the motorhome unattended for an
extended period of time and when driving to
prevent excessive damage and battery discharge
in the event of a leak.
POTABLE WATER
When a city water supply connection is not available,
fill the fresh water tank using the following procedure:
1. Fill a suitable water container with potable water.
2.
Place the suction hose
8
attached to the winterize
by-pass valve into potable water container.
NOTE: The winterize by-pass valve
9
is located in the
exterior utility center.
9
8
3. Turn the winterize by-pass valve
9
to “WINTERIZE”
and water fill selector valve
2
to water tank fill
3
.
4.
Turn on the water pump switch
7
on the system
monitor panel.
5. Depress and hold the fresh water tank level switch
5
to show the percent-full level on the LED display
6
. Once the fresh water level reads full on the LED
display, turn off the water pump.
6.
Turn the winterize by-pass valve
9
to “NORMAL
FLOW” and the water fill selector valve
2
to city
water
4
.
