UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION
65
CLOSING THE ROOF VENT
1. Lift the handle
6
to release it from the seat
7
.
2. Pull down the roof vent using the handle
6
.
3. Ensure latch
5
securely locks the handle
6
in the
closed position.
ADJUSTMENTS FOR DAY/NIGHT
SHADES
The spring tension should be accurately set in order to
rewind the material gradually back into the fully rolled
up position. Too much tension in the spring may cause
damage to the shade material.
REMOVING END CAP
1.
Reach with your hand between the end cap
8
and
the wall as shown in figure
9
.
8
9
2.
Push clip
10
away from the wall with your hands still
in the same position as figure
9
.
10
3. Pull off end cap
8
.
ADJUSTING THE TENSION
INCREASING TENSION
To increase the spring tension remove the end cap,
and use a flat head screw driver to twist the tension
adjustment screw
11
on the left side of the shade
clockwise until the preferred tension is reached. If there
are two shades in the Impulse Platform, you must modify
the tension individually.
1111
DECREASING TENSION
To decrease the spring tension remove the end cap,
and use a flat head screw driver to twist the tension
adjustment screw
11
on the left side of the shade
counterclockwise until the preferred tension is reached.
If there are two shades in the Impulse Platform, you
must modify the tension individually.
