APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME
64
SIDE WINDOW VENTS
Turn the knob
1
counterclockwise to open the window
vent and clockwise to close the window vent.
1
To open egress windows (if equipped), pull up the two
handles
2
, and push out the window.
2 2
MANUAL ROOF VENT
Use the manually operated roof vent
3
in conjunction
with the power roof vent to provide adequate air flow
throughout the motorhome.
The roof vent is equipped with a blind
4
that slides
across the opening to limit the amount of sunlight
entering the motorhome.
1
3
4
ᘐ NOTICE
When leaving the motorhome for extended
periods, ensure all roof vents are fully closed to
prevent rain from entering the coach interior.
OPENING THE ROOF VENT
1.
Press the latch release button
5
on the handle
6
.
2.
Push upwards on the handle
6
and latch the handle
bar into the desired seat
7
.
5
6
7
