APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME
62
MAINTAINING THE ROOF AIR
CONDITIONER/HEAT PUMP
Clean or change the air conditioner filter at least every
two weeks when the air conditioner is in operation. Do
not operate the air conditioner without a filter.
Cleaning/Changing Filter
1. Release the filter cover by depressing the retainer
clip
1
.
2
1
2.
Remove the filter
2
and wash in warm soapy water.
Dry the filter thoroughly before reinstalling. If the
filter is excessively dirty, replace with a new filter.
2
NOTE: Refer to the air conditioner manual in the
Motorhome Information Kit for detailed maintenance
instructions.
COACH POWER ROOF VENT
The coach power roof vent is used to provide controlled
air flow throughout the coachcabin.Usethe vent fan
in conjunction with an open window to provide fresh
air flow.
OPERATING CONTROLS
The on/off switch
3
controls the power to the fan. A
three-position rotary switch
4
controls the fan speed.
Turn the switch clockwise to positions 1, 2, or 3 to set
the fan speeds to low, medium or high respectively.
The roof vent controls include an on/off switch and
a thermostatically controlled fan speed switch. The
12volt DC fan provides proper ventilation, comfortable
temperature control and adequate air flow. It is also used
to vent the shower and toilet. Opening a window while
operating the fan produces maximum air flow. Opening
windows farthest away from the fan will provide the
best air exchange. Open windows sufficiently to allow
proper air circulation.
6
5
3
8
4
7
NOTE: The roof vent must be open at least 3 inches
(76 mm) or the internal safety switch will prevent the
fan from operating.
Thermostat Operation
A rotary thermostat
5
controls the coach cabin
temperature. If the roof vent is open, the fan motor
will start and stop automatically as the interior coach
temperature exceeds or drops below the selected
temperature.
