UNITY MOTORHOME WATER AND PLUMBING SYSTEM
111
WATER PUMP SWITCH
To power the water pump one of the three switches
needs to be turned on. The light
10
above the water
pump switch
7
will light up. To shut down depress any
switch, and the light
10
above water pump switch
7
should turn off. When the water pump is turned “ON” it
will automatically activate when using the shower, toilet
or any faucet. One of the water pump switches is located
on the system monitor panel in the cabinet above the
coach entrance. Additional switches are located in the
bathroom
11
and in the rear utility compartment
12
.
7
10
12
11
DISINFECTING THE WATER
TANK
Periodically disinfect the fresh water system. Disinfect
when the system is new or has not been used for an
extended period of time. Disinfect the water tank as
follows:
1.
Prepare a solution of 1/4 cup household bleach to
1gallon of water.
2.
Place the suction hose
13
attached to the winterize
by-pass valve
14
into the potable water container.
14
13
NOTE: The winterize by-pass valve
14
is located in the
dinette behind the driver’s seat.
3.
Turn the winterize by-pass valve
14
to “WINTERIZE.”
4. Turn on the water pump switch
7
on the system
monitor panel located in the two door wardrobe or
the water pump switches in other locations. Turn
water selector valve
2
to fill.
5. Fill the tank with fresh water. Run water from each
hot and cold faucet until you detect a chlorine odor.
6. Leave the solution in the system for at least four
hours. To reduce the waiting time to only one hour,
double the concentration of household bleach in
your solution.
7.
After the required time has elapsed, drain and flush
the system with fresh water.
