LELY CRS M3 - Air Supply and Network Connectivity; Connected Devices and Network Details

General
• To do maintenance at least one and preferably two wall outlets must be
installed in:
•
The control room
• The room where the central unit is installed
• The tank room (close to the CRS M3)
• The compressor room (close to the compressor)
• If continuous power supply from the grid is not guaranteed, a generator is
an option. For example a tractor driven generator (PTO) or a motor driven
generator:
• The generator must be electronically controlled (brushless).
• The connection power of the generator must be the sum of all
connected equipment (central unit with robot unit(s), compressor, milk
tank, and other (optional) equipment).
• An authorized electrician must approve the final electrical installation
(including grounding) and supply an official report that is given to the Lely
service provider before the first milking is started.
3.3 Pressurized Air Supply
• Pressure input: 6.5 to 7.75 bar (94 to 112 PSI)
• Input air quality: oil free and complied to ISO 8573-1:2001 part 1, class 0
(based on the Atlas Copco classification)
•
Diameter air supply tube: 10 mm (0.39 in)
3.4 Connected Devices
• Maximum no. of robot units: 20
• Maximum no. of clusters: 4
•
Maximum no. of main tanks: 4
• Maximum no. of buffer tanks: 2
• Maximum no. of buffer vessels: 2
3.5 Network Connections
3.5.1 T4C Network
• Data transfer speed: 10/100 Mbit/s
Network cable
• S-FTP 200 MHz Cat5e with shielded connections
•
Number of wires: 8 (4 twisted pairs)
• Max. length of a single cable: 100 m (328 ft)
3-2 Specifications
