5-8 Operating Instructions
Filling sequence of sample bottles
Rack with 40 or 60 Sample Bottles (optional)
1
25
13
37
49
7
19
31
43
55
60
48
36
24
12
Figure 11. Rack with 60 sample bottles
KEY: 1. Rack
Start position
Below left
Number of the 1st bottle
1
Number of steps/sample
2
