Frontview
ThinkPadPortReplicatorSeries3andPortReplicatorSeries3withUSB3.0
1 Powerbutton:Pressthisbuttontoturnthecomputeronoroff.
2 Ejectbutton:Pressthisbuttontoreleasethecomputerfromtheportreplicator.
3 Slidingadjuster:Usetheslidingadjusterasaguidetoalignthedockingstationconnectoronyour
computerasyouattachtheportreplicator.
4 Dockingstationconnector:Thisiswhereyouattachyourcomputer.
ThinkPadMiniDockSeries3andMiniDockSeries3withUSB3.0
1 Powerbutton:Pressthisbuttontoturnthecomputeronoroff.
2 Keylockindicator:Thisindicatorlightswhenthesystemlockkeyisinthelockedposition.Whenthe
systemlockkeyisinthelockedposition,theejectbuttonofthedockingstationislocked;youcannot
attachorremoveyourcomputer.
3 Dockingstationindicator:Thisindicatorlightswhenyourcomputerisdocked.
4 Ejectbutton:Pressthisbuttontoreleasethecomputerfromthedockingstation.
5 Slidingadjuster:Usetheslidingadjusterasaguidetoalignthedockingconnectoronyourcomputeras
youattachthedockingstation.
92UserGuide
