Lenovo ThinkServer TS430 Hardware Maintenance Manual

8.PositionthenewPCIcardonthePCIcardslotforwhichyouhaveremovedtheslotbracketandthen
carefullypressthePCIcardstraightdownuntilitissecurelyseatedintheslot.Installthescrewto
securethePCIcardinplace.
Note:YourPCIcardmightlookdifferentfromthefollowingillustrationdependingonthespecictype.
Figure47.InstallingaPCIcard
9.DependingonthetypeofthePCIcard,youmightneedtoconnectanyrequiredcables.Refertothe
documentationthatcomeswiththePCIcardforspecicinformation.
10.InstallthePCIcardbracketassemblyifaRAIDcardisinstalledinyourserver.See“Removingand
reinstallingthePCIcardbracketassembly”onpage91
.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage177.
RemovingaPCIcard
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstandingthe“Safetyinformation”
onpageiiiand“Guidelines”onpage85.
ThistopicprovidesinstructionsonhowtoremoveaPCIcard.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:UseanydocumentationthatcomeswiththePCIcardandfollowthoseinstructionsinadditionto
theinstructionsinthistopic.
ToremoveaPCIcard,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
100ThinkServerTS430HardwareMaintenanceManual
