Lenovo ThinkServer TS430 Hardware Maintenance Manual

Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage177.
•Afterasystemboardisreplaced,dothefollowing:
1.StarttheSetupUtilityprogrambypressingtheF1key,andthenchecktheBIOSandBMCversion.
2.Gotohttp://www.lenovo.com/driversandfollowtheinstructionsontheWebpagetodownloadthe
latestversionofrmware.Then,installthermwaretoyourserver.
3.Updatethemachinetype,modelnumber,andserialnumberofthesystemboard.Eitheryouwill
bepromptedtodothiswhileupgradingtheBIOS,oryoucanlocatethelesforupdatingthe
VPDwithintheDOSBIOSpackage.Forsomeservers,theVPDutilityisavailablefordownload
at:http://www.lenovo.com/drivers
Note:IfyouwanttousetheFirmwareUpdaterprogram,ensurethatitcontainsthelatestversionsof
thermware.Youcangotohttp://www.lenovo.com/driversandcomparereadmelesofdifferent
versionsofthesamermwareforanindividualdevice.
Completingthepartsreplacement
Thistopicprovidesinstructionstohelpyoucompletethepartsreplacementandturnonyourserver.
Tocompletethepartsreplacement,youmustproperlyroutethecablesinsidetheserver,reinstalltheserver
cover,reconnectalltheexternalcablesand,forsomedevices,updatethermwareandruntheSetupUtility
programtodofurthersetup.
Reinstallingtheservercoverandreconnectingcables
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstandingthe“Safetyinformation”
onpageiiiand“Guidelines”onpage85.
Thistopicprovidesinstructionsonhowtoreinstalltheservercoverandreconnectcablestoyourserver.
Attention:Forpropercoolingandairow,reinstalltheservercoverbeforeturningontheserver.Operating
theserverforextendedperiodsoftime(morethan30minutes)withtheservercoverremovedmight
damageservercomponents.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
Toreinstalltheservercoverandreconnectcablestoyourserver,dothefollowing:
1.Makesurethatallcomponentshavebeenreassembledcorrectlyandthatnotoolsorloosescrewsare
leftinsideyourserver.
2.Makesurethatallinternalcablesareroutedcorrectlyandsecuredbyanycableclipsortiesinthe
server.Keepcablesclearofthehingesandsidesoftheserverchassistoavoidinterferencewith
reinstallingtheservercover.
3.Ifyouhaveremovedthefrontbezel,reinstallit.See“Removingandreinstallingthefrontbezel”on
page89.
Chapter6.Installing,removing,orreplacinghardware177
