Lenovo ThinkServer TS430 Hardware Maintenance Manual

13.AlignthetopedgeoftheEMI-protectivepanelwiththetopsideofthehard-disk-drivecageandthen
pivottheEMI-protectivepaneldownuntilitsnapsintoposition.
Figure78.InstallingtheEMI-protectivepanel
14.Closeandlockthefrontdoor.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage177.Then,youmight
needtorecongureRAIDforyourserver.See“ConguringRAID”onpage73.
Replacingthehot-swaphard-disk-drivebackplane
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstandingthe“Safetyinformation”
onpageiiiand“Guidelines”onpage85.
Thistopicprovidesinstructionsonhowtoreplacethehot-swaphard-disk-drivebackplane.
Thistopicappliesonlytoservermodelsthathavehot-swapharddiskdrivesinstalled.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
Toreplacethehot-swaphard-disk-drivebackplane,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
142ThinkServerTS430HardwareMaintenanceManual
