10.AlignthetopedgeoftheEMI-protectivepanelwiththetopsideofthehard-disk-drivecageandthen
pivottheEMI-protectivepaneldownuntilitsnapsintoposition.
Figure73.InstallingtheEMI-protectivepanel
11.DisconnecttheSATAcablefortheremovednon-hot-swapharddiskdrivefromthesystemboardand
savethecableforfutureuse.
12.Closeandlockthefrontdoor.
13.Ifyouareinstructedtoreturntheoldnon-hot-swapharddiskdrive,followallpackaginginstructionsand
useanypackagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheremovalprocedure,goto“Completingthepartsreplacement”onpage177
.Then,you
mightneedtorecongureRAIDforyourserver.See“ConguringRAID”onpage73.
Installinganon-hot-swapharddiskdrive
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstandingthe“Safetyinformation”
onpageiiiand“Guidelines”onpage85.
Thistopicprovidesinstructionsonhowtoinstallanon-hot-swapharddiskdrive.
Beforeyoubegin,considerthefollowinghard-disk-driveinstallationrules:
•Followtheorderofthehard-disk-drivebayswheninstallingaharddiskdrive.See“Servercomponents”
onpage25
tolocatethehard-disk-drivebaysinyourserver.
•ForRAIDconguration,theharddiskdrivesmustbethesametypewiththesamecapacityiftheyare
withinasingleRAIDarray.Formoreinformation,see“ConguringRAID”onpage73.
Chapter6.Installing,removing,orreplacinghardware137
