28IntelligentDiagnosticsModuleconnector
UsedtoconnectthecableoftheIntelligentDiagnosticsModuleifyourserverhasoneinstalled.
29Internalserialconnector
Usedtoprovideanoptionalserialconnectorsolutionwitharequiredcable.
30PCIcardslot(PCIslot1)
Usedtoinstallastandard32-bit33MHzPCIcardwith167mm(6.57inches)inlength.
31PCIExpressx8cardslot(PCI-Eslot2)
ThisPCIcardslotsupportsaPCIExpressx8cardwith167mm(6.57inches)inlength,suchasanEthernet
card.
32ThinkServerManagementModulechip
WiththeintegratedTMMchip,nomatterwhatconditiontheserveroperatingsystemisinandnomatterif
theserverisonoroff,aslongastheserverisconnectedtonetworkandanacpowersource,theinteraction
withtheTMMcontrolledserverscanbeachievedthroughsystemnetwork.Theusercanobtaintheserver
hardwarehealthinformationandSEL,andisabletoconducttheoperationsincludingturningonorofthe
server,restartingtheserver,andsoon.Thispartoftheservermanagementisindependentoftheoperating
systemandiscalledout-of-bandmanagement.
33PCIExpressx8cardslot(PCI-Eslot3)
ThisPCIcardslotsupportsaPCIExpressx8cardwith167mm(6.57inches)inlength,suchasanEthernet
card,aHBAoraRAIDcard.
34PCIExpressx16cardslot(PCI-Eslot4)
ThisPCIcardslotsupportsaPCIExpressx16cardwith167mm(6.57inches)inlength,suchasanEthernet
card.
35Microprocessorfanconnector
Usedtoconnecttheheatsinkandfanassemblycable.
36Systemfan3connector
Usedtoconnecttherearsystemfancable.
37Microprocessorpowerconnector
Usedtoconnectthe8-pinP2powerconnectorofthepowersupplytoprovidepowertoyourmicroprocessor.
Systemboardjumpers
Thistopicprovidesinformationaboutthejumpersonthesystemboard.
Ajumperisashortlengthofconductorusedtosetuporadjustprintedcircuitboards,suchasthesystem
boardofacomputer.Ajumperusuallyisencasedinanon-conductiveblockofplasticforconvenientuse
andavoidinganypossibledamagetoalivecircuit.Jumperpinsarrangedingroupsonthesystemboardare
